Size
9.5” (L) x 6.4” (W) x 8.3” (H)
Weight
4.96 lb / 2.25 kg
Display
8.4″ color TFT LCD touchscreen
Power
Input: AC 100 V～240V, 50/60Hz
Battery type: lithium-ion battery
Battery capacity: 2600mAh
Network Connection
Wired LAN, RJ45 port
Working Mode
Monitoring mode, Demo mode, Standby mode
Warranty
2 year (service life: 5 years)
Demo Password
1112
Lead section
I, II, III, aVR, aVL, aVF, V1-V6
Gain selection
×1/4, ×1/2, ×1, ×2, ×4 and automatic
Sweep speed
3.125, 6.25, 12.5, 25, 50mm/s
Heart rate range
15~350bpm
Calibration
±1mv
Accuracy
±1bpm or ±1% (select the bigger data)
Defib-proof & ESU-proof
Yes
Pacemaker monitoring
Yes
Display type
Waveform, Data
Measurement range
0~100%
Accuracy
±3% (between 70%~100%)
SpO2 resolution
1%
Pulse rate range
25~250bpm
Accuracy
±1bpm or ±2% (select the bigger data)
Measurement range
30 ~ 250 bpm
Measurement precision
±1bpm or ±2 %, whichever is greater
Resolution
1bpm
Method
Oscillometry
Measurement parameter
Systolic, Diastolic, Mean
Measurement method
Manual, Auto, Continuous
Measuring range
SYS: 30-270mmHg
DIA: 10-200mmHg
MAP: 20-220mmHg
Resolution
1mmHg
Accuracy
Max average error: ±5mmHg
Max standard deviation
8mmHg
Measurement interval in auto mode
2/3/4/5/6/7/8/9/10/15/20/25/30/35/40/45/50/55 minutes and 1/1.5/2/2.5/3/3.5/4/4.5/5/5.5/6/6.5/717.5/8 hours
Oscillometry
5 minutes
Method
Thoracic impedance
Measurement precision
±1rpm or ±5 %, whichever is greater
Resolution
Resolution
Lead option
lead I, lead II and lead III; default lead II
Channel
dual-channel
Measurement and alarm range
77.0°F to 113.0°F
Resolution
0.1 °F
Accuracy
±0.3 °F
Recording speed
25 mm/s; 50 mm/s
Paper size
50mm x 20m
Waveform width
48mm
Total waveform number
3
Type of EtCO2 Sensor
SideStream
Measurement range
0%~19.7%, 0~150mmHg, 0~20kpa
Accuracy
0~40mmHg ±2mmHg
41~70mmHg ±5% of reading
71~100mmHg ±8% of reading
101~150mmHg ±10% of reading
