Size
6.9″*8.3″*3.1″
Weight
2.9lb
Display
8″ color touchscreen
Power
Input: AC 90 V～240V, 50/60Hz
Output: DC 12V ~ 20V
Battery capacity: 2200mAh
Type of Battery
Built-in rechargeable lithium battery
Type of EtCO2 Sensor
SideStream
Life of Main Unit & EtCO2 Sensor
5 years
Warranry
1 year
Admin Password
5188
Demo/User Key
2016
Menu Language
English/Chinese/French/Russian/Turkish/Spanish/Portuguese
Lead Mode
5 Leads or 3 Leads
5 Leads ( R, L, F, N, C or RA, LA, LL, RL,V)
Lead selection: I, II, III, avR, avL, avF, V,
Waveform: 3 ch
3 Leads ( R, L, F or RA, LA, LL)
Lead selection: I, II, III,
Waveform: 1 ch
Gain
x2.5mm/mV, x5.0mm/mV, x10mm/mV, x20mm/mV, auto
HR and Alarm
Range: Adult: 15-300 bpm, Neonate/Pediatric: 15-350 bpm
Accuracy: ± 1% or ± 1bpm, which great
Resolution: 1 bpm
Sensitivity: > 200 (uV P-P)
Differential Input Impedance
> 5 MΩ
CMRR
Monitor: > 105 dB, Operation: > 105 dB, Diagnosis: > 85 dB
Electrode Offset Potential
±300mV
Leakage Current
< 10 uA
Baseline Recovery
< 3s after defi
ECG Signal Range
±8mV (Vp-p)
Bandwidth
Surgery: 1-15 Hz, Monitor: 0.5-35 Hz, Diagnostic: 0.05-100 Hz
Calibration Signal
1 (mV p-p), Accuracy: ±5%
Method
Oscillometric
Mode
Manual, Auto, STAT
Measuring Interval in AUTO Mode
1, 2, 3, 4, 5, 10, 15, 30, 60, 90, 120, 180, 240,480 (Min)
Measuring Period in STAT Mode
5 Min
Pulse Rate Range
40 – 240 bpm
Alarm Type
SYS, DIA, MEAN
Measuring and Alarm Range
Adult Mode: SYS: 40-270 mmHg, DIA: 10-215 mmHg, MEAN: 20-235 mmHg
Pediatric Mode: SYS: 40-200 mmHg, DIA: 10-150 mmHg, MEAN: 20-165 mmHg
Neonatal Mode: SYS: 40-135 mmHg, DIA: 10-100 mmHg, MEAN: 20-110 mmHg
Resolution
Pressure 1mmHg
Accuracy
Maximum Mean error: ±5mmHg
Maximum Standard deviation: ±8mmHg
Overpressure Protection
Adult Mode: 297±3 mmHg
Pediatric Mode: 240±3 mmHg
Neonatal Mode: 147±3 mmHg
Method
Impedance between R-F(RA-LL)
Differential Input Impedance
>2.5 MΩ
Measuring Impedance Range
0.3~5.0 Ω
Base line Impedance Range
0-2.5 KΩ
Bandwidth
0.3 ~ 2.5 Hz
Resp. Rate
Measuring and alarm range: Adult: 0-120 rpm, Neo/Ped: 0-150 rpm
Resolution: 1 rpm
Accuracy: ±22 rpm
Apean alarm: 10-40 S
Measuring Range
0-100 %
Alarm Range
0-100 %
Resolution
1 %
Accuracy
70%-100% ±2 %, 0%-69% unspecified
Actualization interval
about 1 second
Alarm Delay
10 seconds
Pulse Rate
Measuring and Alarm Range: 0-254bpm
Resolution: 1bpm
Accuracy : ±2bpm
Channel
1
Measuring and Alarm Range
0-50℃
Resolution
0.1℃
Accuracy
± 1%℃
Actualization interval
about 1 second
Average Time Constant
<10 seconds
