128 Elements Dual-Probes Whole Body Portable Ultrasound Scanner
C10RL
Categories: 128, Cardiology, Color, Convex Probe, Emergency Medicine, Imaging, Internal Medicine, Linear Probe, Primary Care, Sports Medicine
Specifications
Specifications 2
Specifications
Weight
250g
Battery working time
3hours (Working time), 12 hours(Stand by time)
Gain
40-110Db
Display mode
B, B+B, B/M, Color, PW, PDI, B+Color+PW
Supporting system
IOS, Android, Windows
Scanning Depth
90-305mm, 20-100mm, 90-160mm
Elements
Dual 128
Frequency
3.5/5.0mhz, 7.5/10mhz,2.5/5.0mhz
Specifications 2
Screen
Tablet, Smart phone, PC
lmage gray scale
256 level
Measure
B: Length, Area/Circumference, Angle, Trace, Distance GA(CRL,BPD,GS,FL,HC,AC)EFW(BPD,FL)
B+M: Heart rate, Time, Distance, LVID(LVIDd, LVIDs, EF, SV)
B+PW: Velocity, Heart rate(2), S/D, Depth.
Automatic Vessel Flow Measure：PS, ED, TAMAX, TAMEAN, PI, RI, S/D, DIAM, FL
Power
by built-in Lithium battery
