128 Elements 7.5-10Mhz B&W Linear Probe Portable Ultrasound Scanners
C10LN
Categories: 128, Application, Black and White, Imaging, Internal Medicine, Linear Probe
Specifications
Specifications 2
Specifications
Probe
Wireless linear probe
Scanning Depth
40-60-80-100mm
Battery working time
3hours (Working time), 12hours (Stand by time)
Gain
40-110Db
Display mode
B, B/M
Supporting system
IOS/Android/Windows
Software Adjustable Parameters
GN(gain), D(Depth), ENH(Enhancement), DR(Dynamic range), F(Frequency), FocusPos, PRF, WF, Mode, 8TGC, Biopsy, Annote
Elements
128
Frequency
7.5-10Mhz
Specifications 2
Screen
Tablet, Smart phone, PC
WiFi Type
Built-in WiFi, 802.11g/20MHz/2.4G/450Mbps
Presets
Thyroid, Small parts, Pediatrics, Vascular, Carotid, Breast, MSK, Nerve，Aesthtics, user1，user2
Frame
24s/f
WiFi Type
Built-in WiFi, 802.11g/20MHz/2.4G/450Mbps
Measure
B: Length, Area, Circumference, Angle, Trace, Distance
B+M: Heart rate, Time, Distance
Power
by built-in 4200mAh battery
