Size
12.2″×6.4″×7.4″
Weight
6.0lb (Rechargeable lithium battery included)
Display
10.4″ color TFT-LCD
Power
Power supply: 100-240VAC, 50/60Hz
Battery capacity: 2600mAh (>2 hours)
WARRANTY
2 years (Service life: 5 years)
FDA 510(K) CLEARANCE
Yes
CE CERTIFIED
Yes
DATA STORAGE
360 hours of trends, 1,000 alarm events with waveforms, 500 arrhythmia events with waveforms, 1,500 NIBP records, 48 hours of full waveform data
NETWORK CONNECTION
Wired LAN, RJ45 port; HL7 compatible
DISPLAY VIEWS
Preset display views: 1 ECG, 2 ECGs, 3 ECGs, 7 ECGs, 9-Channel, Mini Trend, OxyCRG, Big Waveform, Huge Digit; 5 customizable views
DRUG DOSE CALCULATION
17 drug types (14 preset, 3 customizable)
WORKING MODE
Monitoring mode; Demo mode; Standby mode
INGRESS PROTECTION
IPX2
SUITABLE FOR
Adults, Pediatrics, Neonates
ECG lead selection (5-lead)
I, II, III, aVR, aVL, aVF, V
Gain selection
×1/4, ×1/2, ×1, ×2, ×4 and automatic
Sweep speed
3.125, 6.25, 12.5, 25, 50mm/s
Heart rate range
15-350bpm
Calibration
±1mV
Accuracy
±1bpm or ±1% (whichever is greater)
ECG filter modes
MON, DIA, OPR
Defib-proof & ESU-proof
Yes
Pacemaker detection
Yes
ARRHYTHMIA DETECTION (34 TYPES)
Afib(C), Afib(F), Atr Flutt, Sinus Arr, Missed Beat, Atr Tach, P Atr Tach, Nodal, SVT, Tachycardia, Extreme Tachycardia, Bradycardia, Extreme Bradycardia, PAC, PNC, PVC1-LV, PVC1-LV Early, PVC1-LV RonT, PVC2-RV, PVC2-RV Early, PVC2-RV RonT, Multi PVCs, PVCS 6/Min, PVCS 12/Min, PVCS 24/Min, Freq MF, Bigeminy, Trigeminy, Pair PVCs, Run 5 PVCs, Run 11 PVCs, V Tach, Asystole, 1st DEG BLK.
ST Measurement range
−2.55 to +2.55 mV
ST Measurement accuracy (−0.8 to +0.8 mV)
±0.02 mV or ±5%, whichever is greater
ST Resolution
0.01 mV
Default ST (II) alarm limits
High 0.20 mV / Low −0.20 mV
Display type
Waveform, Data
Measurement range
0-100%
Accuracy
±3% (70%–100%)
SpO2 resolution
1%
Pulse rate range
25-250bpm
Accuracy
±1bpm or ±2% (whichever is greater)
Measurement range
30 – 250 bpm
Measurement precision
±1bpm or ±2 %, (whichever is greater)
Resolution
1bpm
Method 1
Thoracic impedance
Measurement precision
±1rpm or ±5% (whichever is greater)
Resolution
1rpm
Lead option
Lead I, lead II and lead III; Default lead II
Method 2
Nasal airflow respiration
Method
Oscillometry
Measurement parameter
Systolic, Diastolic, Mean
Measurement method
Manual, Auto, Continuous
Measuring range
SYS: 30-270mmHg
DIA: 10-200mmHg
MAP: 20-220mmHg
Resolution
1mmHg
Accuracy
Max average error: ±5mmHg
Max standard deviation
8mmHg
Measurement interval in auto mode
2/3/4/5/6/7/8/9/10/15/20/25/30/35/40/45/50/55 minutes and 1/1.5/2/2.5/3/3.5/4/4.5/5/5.5/6/6.5/7/7.5/8 hours
Measurement time in continuous mode
5 minutes
Channel
Dual-channel
Measurement and alarm range
77.0°F to 113.0°F
Resolution
0.1 °F
Accuracy
±0.3 °F
Recording speed
12.5 mm/s; 25 mm/s; 50 mm/s
Paper size
50mm x 20m
Waveform width
48mm
Maximum waveforms displayed
3
Alarm auto print
Yes
